Aris TableTop The Most Advanced Active Vibration Isolation System with Built-In Shaker Mode

Aris TableTop

The Most Advanced Active Vibration Isolation System with Built-In Shaker Mode

Brand:

K&S Advanced Systems

Category:

Active Vibration Isolation Systems

ArisTT - Active Vibration Isolation System with Built-In Shaker Mode

The Aris TableTop - Most Advanced Active Vibration Isolation System with Build-In Shaker Mode

Vertical/Lateral Transmissibility

Without Active Vibration Isolation

With Active Vibration Isolation

A lightweight and compact table top active vibration isolation system that counteracts unwanted vibrations for sensitive equipment. The streamlined design allows it to seamlessly become part of the workstation environment, and its straightforward composition requires no follow-up tuning.

Aris’s effectiveness at significantly reducing vibrations and disturbances marks it as a revolutionary and critical tool for laboratory use.

Files

Attachment	Size
Aris TableTop Brochure	918.83 KB

Special Built-In Shaker Mode

Understand how your system/device performs under Vibration Conditions

Allow to test how the target system or device performs under different vibration conditions
Adjustable for different frequencies and amplitudes
Simulation of real-world environmental conditions
Verification of target system or device internal components responses to vibrations
Uses standard external sensors to understand the effect of vibration and vibration induced internal components resonances on target system's performance
Provide ability to learn target system limitations
Ability to collect and analyze data in a form of Transmissibility

Technology Principle

K&S active vibration isolation are based on advanced technology, that combines up to three independent layers of active vibration cancelation and two layers of passive. The extensive flexibility of such system architecture allows K&S systems to get maximum performance in installations, especially in cases where the typical system would be impossible to use.

Technical Features


Patented Architecture
Active Vibration Isolation in all Six Degrees of Freedom
Active Vibration Control Bandwidth 0.5Hz - 100Hz
Highly Damped Step Respond
No tuning required - Simple installation
Fit most lab AFMs and Desktop SEMs
Desktop Power Supply 90-240VAC, 150W
Average Power Consumption around 30W
Can operate in series with Tool's internal vibration isolation system
Custom dimensions and special attachments available upon request
Counteracts unwanted vibrations for sensitive equipment
Significantly reduces vibrations and disturbances
Seamlessly integrates into the workstation environment

ArisTTxxx Products Line - Active Vibration Isolation Systems

ArisTTxxx-s Built-in Shaker Capabilities

Allowing to test how target system or device performs under different vibration conditions
Adjustment for different frequencies and amplitudes
Reprodusing real-world environmental conditions to verify target system internal components responses to vibrations
Built-in ability to collect and analyze data


ArisTTxxx Products Line	Device Capabilities	Device Dimensions (mm)	Load Capacity (kg)
ArisTT75	Active Vibration Isolation System	300x450x62	15-75
ArisTT75x	Active Vibration Isolation System	400x500x80	15-75
ArisTT100	Active Vibration Isolation System	400x500x80	40-100
ArisTT150	Active Vibration Isolation System	400x500x80	70-150
ArisTT180	Active Vibration Isolation System	500x600x80	80-180
ArisTT200	Active Vibration Isolation System	600x800x80	90-200
ArisTT150-s	Active Vibration Isolation System with Built-in Shaker	400x500x80	70-150
ArisTT180-s	Active Vibration Isolation System with Built-in Shaker	500x600x80	80-180
ArisTT200-s	Active Vibration Isolation System with Built-in Shaker	600x800x80	90-200
ArisTTxxx-m	Active Vibration Isolation System with Built-in Shaker	Modified Size	Customized
